• Contact Resistance：≤50mΩ
• Insulation Resistance：≥100MΩ
• Dielectric Strength：250V.AC.1Min
• Operating Force：250±30gf
• Rated Values：0.5A/12V
• Climate Grade：-30℃ ~70℃
• Travel：0.30±0.02
• Life：5,000,000cyces-10,000,000cyces
|
 |
   |
| Part Number | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Rated Values | Climate Grade | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R0190-H-3-R-V-B | ≤50mΩ | ≥100MΩ | 250V.AC.1Min | 250±30gf | 0.30±0.02 | 5,000,000cyces-10,000,000cyces | 0.5A/12V | -30℃ ~70℃ | 暫無(wú) |
| R0190-H-1-R-V-B | ≤50mΩ | ≥100MΩ | 250V.AC.1Min | 250±30gf | 0.30±0.02 | 5,000,000cyces-10,000,000cyces | 0.5A/12V | -30℃ ~70℃ | 暫無(wú) |
| R0190-M-2-R-V-R | ≤50mΩ | ≥100MΩ | 250V.AC.1Min | 250±30gf | 0.30±0.02 | 5,000,000cyces-10,000,000cyces | 0.5A/12V | -30℃ ~70℃ | 暫無(wú) |
| R0190-H-2-R-V-B | ≤50mΩ | ≥100MΩ | 250V.AC.1Min | 250±30gf | 0.30±0.02 | 5,000,000cyces-10,000,000cyces | 0.5A/12V | -30℃ ~70℃ | 暫無(wú) |
